Masterblend El Diablo Truckmount

Masterblend El Diablo Truckmount

Part #: 300011

Call for Price - (800) 856-8223 or Contact Us

*Prices are subject to change without notice.

El Diablo Truck Mount

Sweet Simplicity!

Simple is better. If you have ever owned a truck mount before, you likely recognize that SIMPLE IS GOOD! With the El Diablo Truck Mount everything is designed for easy access. This is a powerful kerosene truck mount with a 75-gallon (10-year warranty) stainless steel recovery-tank. Features a unique vacuum-relief system that allows for long hose runs, up to 500 to 700 feet.

Standard Features

  • Kohler 27-HP V-Twin Engine
  • Roots 4.5 Whispair Dual-Splash Lubricated Blower
  • Cat 3CP 2000 psi, high-pressure pump
  • Clutch for flood work
  • 195,000 BTU Kerosene
  • Optional 125,000 BTU Propane Heater
  • 75-gallon stainless steel recovery-tank


Specifications

  • Dimensions: 36"w X 39-3/8"h* X 45-1/4"l
  • 42-1/2" to top of vacuum connections
  • Heater: 14"w X 36-1/4"h X 14"
  • 22" with fittings
  • Heater Frame: 17-1/8" x 17-1/8"
  • Console: 400 lbs.
  • Waste Tank: 100 lbs.
  • Heater: 75 lbs.

VARIATIONS GO HERE

Part #: 300011
Description: 45 / Kerosene
Our Price: $17,995

Part #: 300001
Description: 45 / LPG
Our Price: $17,995




Shipping Weight: 600.0 lb
Part #: 300011
